Specifications
1,Energy-saving and cost-reducing
2,Simple structure, practical and economical
3,High efficency, short gas filling process
Detial:
1,Natural gas filling volume: 2200M3
2,Ideal distance: within 80km
3,Low cost and durable
| Category of vessel |
Three type |
pad -dry-cure process |
integrally annealed |
| working temperature |
-19°C-50°C |
water pressure test |
6.15MPa |
| design temperature |
-19°C |
cylinder head material |
16MnR |
| working pressure |
4.0MPa |
kinds of flange material |
16MnⅢ |
| design pressure |
4.1MPa |
tank quality |
26948Kg |
| design volume |
56 m3 |
design thickness |
body |
31.57mm |
| filling medium |
nature gas |
head |
31.38mm |
| corrosion allowance |
1.0mm |
dimension φ2400×32×12974 |
| welded joint coefficient |
1 |
