说明
1. 内部的排放设施安装在气瓶上，用来排放任何时候汽瓶中的残余溶液。这样就会阻止残余溶液中的硫化氢对气瓶瓶体产生的压力腐蚀，以此达到延长气瓶寿命的目的；
2.设施安全；
3.安装气瓶的钢带变得更宽，螺栓更大；
| Trailer chassis |
Item |
|
Data |
CNG
Bottle type pressure vessel
|
Item |
Data |
| Model |
|
HDS9340GGQ |
Norminal pressure MPa |
20 |
| Curb weight KG |
|
32400 |
Operating ambient temperature °C |
-50~60 |
| Semitrailer full load weightKG |
|
35600 |
Filling medium |
Natural gas |
|
Full of axle load distribution
|
Fifth wheel KG |
13500 |
Container nubmer |
8 |
| |
Backshaft
KG
|
22100 |
Geometric volume m3 |
17.92 |
|
Leg load
KG |
|
19450 |
Filling CNG volumeNm3 |
4550 |
|
Front fitting radius
mm |
|
1950 |
Filing weight KG |
3200 |
|
Back fitting radius
mm |
|
2100 |
Body weight KG |
23268 |
|
No-load traction combined with surface Height
mm |
|
1245 |
Hydrostatic test MPa |
33.3 |
| |
|
|
Gas tight tes MPa |
20 |
| air tight test pressure MPa |
|
20 |
|
| Dimension (length*width*height)mm |
|
12391×2480×3000 |
External dimension mm |
φ559×16.93×10950 |
