LNG 1.44MPa Working Pressure 54M3 Effective Capacity Tank Container
Full capacity: 60M3
Effective capacity: 54M3
Max. working pressure: 1.44MPa
Outer dimension: 13530*2924*3380MM
Weight: 25050KG
Evaporation rate: (LIN) 0.14%/d
Gas supply: /
Insulation method: High vacuum multi-layers
Our cryogenic tanks conform to GB150, GB18442 standard and ASME standard, are suitable for liquefied natural gas (LNG) etc. cryogenic liquid storage and application. Different volumes of tanks are available, and the maximum allowable working pressure is 0.8MPa and 1.2MPa.
We adopt advanced vacuum acquisition and maintenance technology to guarantee good insulation performance, long vacuum holding time and low maintenance cost.
External pipelines adopt modular design and prefabrication, which can be more compact and concise, and the user can get more reliable system, more convenient installation, maintenance and lower maintenance costs.
It passes CCS attestation and can meet international marine requirements with certificate issued by International Classification Society according to user’ demand.
******************************************************************************************
